Features

• 2.4MP Image Resolution, True Color
• AHD/TVI/CVI Standard and Lossless Video Output
• CMOS Progressive Scan, Perfectly Capture the Moving Object
• Support OSD Menu
• High Speed, Long Distance and Real time Transmission
• Auto Color to B/W at Low illumination
• Support ICR Switch, True Day/night
• 20m IR night View Distance
• Support COC / IP66

Specifications

• Image Sensor : 1/3.2”CMOS
• Lens : 3.6mm horizontal field of view: 86.6° , 6mm horizontal field of view: 56
• Angle of View (H) : 86.6°
• Day/Night : ICR
• Shutter Speed Auto : 1 / 50s ~ 1 / 100000s ( PAL )
• Min.Illumination : 0 lux (IR ON)
• IR : 20m
• WDR : DWDR
• Digital Zoom : 16x
• Video Output : AHD/TVI/CVI/CVBS
• Power : DC 12V(± 10%)
• Power Consumption : IR Off : 1W: IR On : 3W
• Working Humidity : 10%~90% (relative humidity)
• Working Environment : -30°C~50° C
• Dimension : Ф 65 x 144
• Weight : Approx. 0.15KG
